Follow the seven steps below before downloading the model-specific assembly guide for your enclosure.

1. For ease of assembly, lay out all the pieces and have the poles arranged in size order (see image). Quantities will vary depending on model.

2. Start building the enclosure by placing the base corner units and joining poles to make the base frame as shown below. Lay the fabric down making sure the Velcro straps are at the back and the plush side of the fabric is face down.

3. Insert the top centre poles through the fabric pockets on both sides. Then connect these poles to the upper side sections as shown in the images below.

4. Next attach the front centre poles to both top corners to complete the frame of the enclosure.

5. First secure the Velcro around the front poles and then around the base poles. Next attach all the rear Velcro straps around the rear poles and tighten the fabric.

6. Begin by attaching the impact screen to the inner Velcro strips, starting at one of the corners. Use the long bungee toggles to secure the top and the shorter toggles for the sides, fastening them to the rear of the screen and around the poles.

7. Click on the correct SIM model below for Pole Assembly Instructions. Click on Full Installation Manual for full enclosure setup instructions.
